Twelve workshop terms, each defined plainly and paired with the real figures from the ZHIDA product range so you can check the definition against actual equipment. Every term links through to its category.
A motorcycle lift is a long platform with a ramp that a motorcycle is rolled onto and raised by hydraulic, pneumatic or electric power. Used for service work performed standing up, with the bike's wheels resting on the deck.
In the ZHIDA range: capacities from 1000 lb; 800 lb; weights from 95 to 130 kg, across 6 models.
Examples: ZD04081-400, ZD04101-450, ZD04101D-450, ZD04102.
A ATV/Dirt jack is a compact platform, typically 300 to 450 mm across, pushed under a stationary bike's frame to raise the wheels clear of the ground. Used for wheel, fork and swingarm work.
In the ZHIDA range: capacities from 1000 lb; 1100 lb; 1500 lb; 300 lb; 360 lb; weights from 7.5 to 29 kg, across 10 models.
Examples: ZD05153D-J, ZD05153F, ZD04301, ZD04303.
A hydraulic shop press is a fixed steel frame carrying a hydraulic ram above an adjustable bed plate. Workpieces are brought to the press for bearing fitting, pressing and straightening.
In the ZHIDA range: capacities from 10 ton; 20 ton; 30 ton; 4 ton; 40 ton; weights from 32 to 229 kg, across 15 models.
Examples: ZD07041, ZD07101, ZD07102, ZD07103.
A porta power is a portable hydraulic set: hand pump, hose, ram, extension tubes and interchangeable heads supplied in a carrying case. Used to push, spread or bend material that cannot be brought to a press.
In the ZHIDA range: capacities from 10 ton; 2 ton; 20 ton; 2T / 4T/ 5T / 10T N.W. 23 kg; 4 ton; weights from 17 to 33 kg, across 8 models.
Examples: ZD01042, ZD01102, ZD01103, ZD01201.
A transmission jack is a lifting device with a tilting, strapped saddle designed to cradle a gearbox during removal and installation. Two families exist: high-lift units used with a vehicle lift, and low-profile units for ground work.
In the ZHIDA range: capacities from 0.5 ton; 1 ton; 1.5 ton; 2 ton; 850-1750 mm | N.W. 54 kg; weights from 9 to 91 kg, across 14 models.
Examples: ZD02051-28, ZD02051A, ZD02054, ZD02053.
A floor jack is a low hydraulic trolley that raises a vehicle by a designated jacking point. It lifts and lowers; it is not designed to hold or reposition an unbalanced component.
In the ZHIDA range: capacities from 10 ton; 2 ton; 20 ton; 3 ton; 5 ton; weights from 6.2 to 150 kg, across 5 models.
Examples: ZD2220L, ZD2210L, ZD2205L, ZD22031-D75.
A air jack is a pneumatic lifting device powered by compressed air, used where speed matters. Available from 1.8 to 50 tons for workshop and commercial vehicle use.
In the ZHIDA range: capacities from 1.8 ton; 12 ton; 2.2 ton; 20 ton; 22 ton; weight 36 kg, across 7 models.
Examples: ZD20182, ZD20222, ZD21121, ZD21201.
A jack stand is a fixed-height mechanical support placed under a vehicle that has been raised by a jack. A jack lifts; a jack stand holds. Never get under a load supported only by a jack.
In the ZHIDA range: capacities from 2T / 3T / 6T / 12T 278-428 mm | N.W. 5 kg; 2T / 3T / 6T / 12T 278-428 mm | N.W. 5.5 kg, across 2 models.
A engine crane is a wheeled boom-and-leg hoist used to lift an engine or other heavy assembly out of a vehicle bay, then move it clear.
In the ZHIDA range: capacities from 0.5 ton; 0.75 ton; 1 ton; 2 ton; weights from 5 to 69 kg, across 7 models.
Examples: ZD1001Z-54, ZD1001Z-62, ZD1002Z-CE, ZD1002Z-D.
A engine stand is a wheeled frame that accepts an engine block and holds it at workable height, usually with a rotating head so all sides of the block can be reached.
In the ZHIDA range: capacities from 1000 lb; 1500 lb; 2000 lb; 750 lb; weights from 16 to 48 kg, across 7 models.
Examples: ZD11075, ZD11100, ZD11150A, ZD11150Z.
A wheel dolly is a low wheeled carrier used to move a heavy wheel and tyre assembly, or in lifting versions to raise it towards hub height during fitting.
In the ZHIDA range: capacities from 1000 lb; 1200 lb; 1500 lb; 300 lb; 440 lb; weights from 9 to 56 kg, across 11 models.
Examples: ZD14150, ZD14151, ZD14150-J, ZD14151-J.
A hose reel is a spring or motor driven reel that stores and dispenses an air, water or oil hose, keeping it off the floor and retracting it after use.
In the ZHIDA range: capacities from 15m Air hose; 15m Water hose; 20m Water hose; 20m Air hose, across 4 models.
Examples: ZD08151A, ZD08151W, ZD08202A, ZD08202W.
Full buying guides: motorcycle lifts, shop presses, transmission jacks and engine cranes and stands. Full range at the product catalogue.
A jack lifts, a jack stand holds. Hydraulic jacks can creep or fail under sustained load, so once a vehicle is raised it should be lowered onto stands before anyone goes underneath.
Product standards vary by market. The ZHIDA press range is split into CE-labelled series covering economic, normal and professional construction, and product pages state which certification applies.
OEM covers building a customer's existing design under their brand. ODM means developing and manufacturing a new product to a customer's requirement - both are supported across the range.
